Choosing the Perfect TV Lift: Technical Requirements and Tips

Ultralift Australia’s motorised TV lifts enhance aesthetics by concealing TVs when not in use, creating a clean and uncluttered living space. These innovative solutions optimize space, making your environment more versatile by freeing up areas for other uses. They also provide safety and protection by retracting TVs into cabinets, reducing the risk of accidental damage or injury, especially in homes with children or pets. With customizable designs, Ultralift ensures seamless integration into any space, tailoring solutions to meet specific needs.

Choosing a ceiling TV lift requires careful consideration of several important factors. This guide is designed to help you navigate those choices and select the ideal solution for your needs. If you have any questions or need assistance, feel free to reach out—we’re here to help every step of the way.

Ultralift’s ceiling TV lifts accommodate a wide range of TV sizes, from 22 inches to over 100 inches. Thanks to our advanced manufacturing capabilities, we can customize lifts to suit TVs of any size and weight.

For larger, heavier TVs, we carefully evaluate the appropriate solution to ensure the lift suits your needs. You’ll also need to ensure that your support structures can handle the weight during installation and beyond. Additionally, if you plan to add cladding to your ceiling panel, please provide the weight details so we can factor this into our design, ensuring optimal performance and safety.

The height of your ceiling plays a key role in determining the most suitable TV lift for your space. Here are some recommendations to help you choose the right lift:

Standard Ceiling Heights

• Spartan and Descender Range: Perfect for standard ceilings, these lifts can tilt up to 15 degrees when fully extended, providing optimal viewing angles.

High Ceiling Applications

• Spartan Drop and Descender Drop: Designed for higher ceilings, these models offer extended travel distance to position the TV at a comfortable viewing height.

Swivel Features

• Spartan Swivel 360: This lift rotates a full 360 degrees, allowing for multiple viewing positions. It’s available for both standard and high ceilings, with an added drop and swivel feature for taller spaces.

Different TV lifts require varying amounts of space within the ceiling cavity.

Here’s what to consider:

Larger Cavity Requirements:

• Descender and Descender Drop: These models move vertically into the ceiling cavity and require 1 to 1.5 times the height of the TV for proper installation.

Smaller Cavity Requirements:

• Spartan Range: These lifts tilt the screen to fit into smaller ceiling cavities, needing a minimum of 135mm of ceiling cavity space.
• Mercury Slim: Ideal for tighter spaces, this model fits into cavities with as little as 110mm of cavity space. If your ceiling cavity is smaller than 135mm, the Mercury Slim is a great alternative.
• Actuators vs. Tubular Motors: The Spartan uses actuators, while the Mercury Slim employs a tubular motor.
• Exposed vs. Hidden Components: The Mercury Slim has visible cables and struts on each side for support, whereas the Spartan keeps all cables concealed, offering a clean appearance when opened.
